AQL 36V 48V 250W 350W Mid Drive Conversion Kit Electric Bicycle Motor Central With Electric Bike Battery
Overview
Quick Details
- Voltage:
-
36V / 48V
- Design:
-
Brushless Mid Motor
- Wattage:
-
250W / 350W
- Product name:
-
AQL MT 1000 motor kit and frame
- Power:
-
250W / 350W
- Motor:
-
Mid Drive Motor
- Controller:
-
Sine Wave
- Display:
-
TFT / LCD
- Speed:
-
25km/h
- Battery:
-
Li-ion Battery
- Rated voltage:
-
36 V / 48V
- Max Torque:
-
120N.m
- Sensor:
-
Torque Sensor
Product Description
|
Output torque
|
120N.m
|
Rated Power
|
250W
|
|
Voltage
|
36V
|
Reduction ratio
|
1:38
|
|
Rotate Speed (rpm)
|
75±5
|
Motor Efficiency
|
≥80%
|
|
Max Speed
|
25Km/h, 35Km/h
|
Warranty
|
2 years
|
|
Range per power
|
40-70Km (10.4Ah)
|
Battery
|
11Ah/13Ah lithium battery (Option)
|
Package content:
| Item name | Description | QTY |
| MT1000 mid drive motor | 36V,250W,include cranks , Torque +speed senor and chain wheel | 1 pcs |
| Dispaly | TFT Display MCPU-2C | 1 pcs |
| Brake levers | Cable brake, cut-off electricity (option:Hydrolic brake) | 1 set |
| Cable with waterproof connector | Include main cable,controller cable, motor cable and brake cable, Waterproof level: IP65 | 1 set |
| Controller | 36V, Sine wave | 1 set |
| Recharger | Lithium battery recharger (42V2A) | 1 pcs |
| OPTIONS FOR YOU | ||
| Throttle (option) | thumb throttle | 1 pcs |
| Battery (Option) | Battery (11Ah/13Ah lithium battery,Samsung cell ) | 1 Pcs |
| Frame (Option) | Customize frame with exclusive mid motor bracket | 1 unit |
