Mid Drive Motor 36V 350W 29 Inch Bike Frame And Electric Bicycle Motor Kit
Overview
Quick Details
- Voltage:
-
36V
- Design:
-
Brushless
- Wattage:
-
201 – 300w
- Product name:
-
AQL MT 1000 motor kit and frame
- Power:
-
250w
- Motor:
-
Mid Drive Motor
- Controller:
-
Sine Wave
- Display:
-
TFT
- Speed:
-
25km/h (EU) 35km/h (US)
- Battery:
-
Li-ion Battery
- Rated voltage:
-
36/48V
- Max Torque:
-
110N.m
- Sensor:
-
Torque Sensor
Product Description
|
Output torque
|
110N.m
|
Rated Power
|
250W
|
|
Voltage
|
36V
|
Reduction ratio
|
1:38
|
|
Rotate Speed (rpm)
|
75±5
|
Motor Efficiency
|
≥80%
|
|
Max Speed
|
25Km/h, 35Km/h
|
Warranty
|
2 years
|
|
Range per power
|
40-70Km (10.4Ah)
|
Battery
|
11Ah/13Ah lithium battery (Option)
|
Package content:
|
Item name
|
Description
|
qty
|
||
|
MT1000 mid drive motor
|
36V,250W,include cranks , Torque +speed senor and chain wheel
|
1 piece
|
||
|
Dispaly
|
TFT Display MCPU-2C
|
1 piece
|
||
|
Brake levers
|
Cable brake, cut-off electricity (option: Hydrolic brake)
|
1 set
|
||
|
Cable with waterproof connector
|
Include main cable,controller cable, motor cable and brake cable, Waterproof level: IP65
|
1 set
|
||
|
Controller
|
36V, Sine wave
|
1 set
|
||
|
Recharger
|
Lithium battery recharger (42V2A)
|
1 piece
|
||
|
OPTIONS FOR YOU
|
||||
|
Throttle (option)
|
thumb throttle
|
1 piece
|
||
|
Battery (Option)
|
Battery (11Ah/13Ah lithium battery,Samsung cell )
|
1 Piece
|
||
|
Frame (Option)
|
Customize frame with exclusive mid motor bracket
|
1 unit
|
||
